We updated out 14 MiniSport and she became a 15 in the process. Don't have much space to build or store a boat but still dream about a pretty Carolina boat. No Problem!
Key Features
- A 15 with Carolina Style and a broken sheer!
- We updated out 14 MiniSport and she became a 15 in the process
Specifications
Specifications, including hydrostatic information, are provided as a convenience only and may change without notice. These proposed targets are approximate and are heavily dependent on choices made during construction such as material weights and other subsequent factors such as engine size and loading of the vessel during actual use.
| Designation: | 14OCCIK |
| Series: | Inshore |
| Centerline Length (Hull): | 15 ft 3 in / 4.65 m |
| Maximum Beam: | 6 ft 6 in / 2 m |
| Target Draft (Hull): | 12 in / 30 cm |
| Notes on Draft: | Predicted draft at Target Displacement (See Notes on Displacement below) |
| Target Displacement: | 2000 lbs / 900 kg |
| Notes on Displacement: | Fully loaded at Designed Waterline: People, Fuel, Motor(s), Consumables, etc. This is a better figure for evaluating a boat in real world conditions. |
| Maximum Horsepower: | 90 |
| Fuel Capacity: | 20 gal / 91 L |
| Deadrise at Transom: | 12° |
| Deadrise at Midships: | 17° |
| Deadrise at Entry: | 40° |
| Waterline Length: | 11 ft 5 in / 3.5 m |
| Hull Surface Area: | 144 sq ft / 13.4 sq m |
| Notes on Hull Surface Area: | When considering a new boat build, the Hull Surface Area is a good indication of the relative size of one boat compared to another. |
