As first real "technical skiff", she is designed for complete composite construction. She is small and light and will get you into ankle deep water. Put a mud motor on her and have some real fun in the skinny water!
Key Features
- As our first real "technical skiff", she is designed for complete composite construction
- She is small and light and will get you into ankle deep water
- She is small and light and will get you into ankle deep water. You can hang a 25 horsepower motor on the back if you build a side console with a wheel. If you tiller steer her, she should have a 15 HP max.
Specifications
Specifications, including hydrostatic information, are provided as a convenience only and may change without notice. These proposed targets are approximate and are heavily dependent on choices made during construction such as material weights and other subsequent factors such as engine size and loading of the vessel during actual use.
| Designation: | 14OFLIO |
| Series: | Flats |
| Centerline Length (Hull): | 14 ft / 4.25 M |
| Maximum Beam: | 4 ft 11 in / 1.5 M |
| Target Draft (Hull): | 5 in / 13 cm |
| Notes on Draft: | Predicted draft at Target Displacement (See Notes on Displacement below) |
| Target Displacement: | 900 lbs / 405 kg |
| Notes on Displacement: | Fully loaded at Designed Waterline: People, Fuel, Motor(s), Consumables, etc. This is a better figure for evaluating a boat in real world conditions. |
| Maximum Horsepower: | 25 |
| Fuel Capacity: | 12 gal / 45 L |
| Deadrise at Transom: | 0° |
| Deadrise at Midships: | 4° |
| Deadrise at Entry: | 45° |
| Waterline Length: | 12 ft 9 in / 3.9 M |
| Hull Surface Area: | 85 sq ft / 7.9 sq M |
| Notes on Hull Surface Area: | When considering a new boat build, the Hull Surface Area is a good indication of the relative size of one boat compared to another. |
